Product Specifications
| Product Model | Brahma AT5/TR Series |
|---|---|
| Control Unit Type | Automatic Flame Safeguard & Gas Burner Ignition Controller |
| Operating Voltage | 230 VAC (+10% / -15%), 50–60 Hz |
| Power Consumption | Approx. 12 VA (During Ignition) / 3 VA (Standby) |
| Ignition System | Built-in Electronic Ignition Transformer (High Frequency) |
| Flame Detection Method | Ionization Flame Sensing Rod |
| Safety Response Time | Flame failure response < 1 second |
| Operating Temperature | -20°C to +60°C (-4°F to +140°F) |
| Enclosure Protection Rating | IP40 (Standard Plug-in Mounting Base) |
| Key Features | Integrated ignition transformer, automatic ignition & purging sequence, instant lockout on flame failure, compact flame safety box, easy plug-in base installation, and high electromagnetic noise immunity. |
