Distributor Sensus Hot Water Meter WP-QF DN 80 PN 40 (130°C) | Industrial Water Meters
Sensus Meter Series 🔥 Up to 130°C Hot Water ⚡ PN 40 High Pressure

Sensus Hot Water Meter WP-QF DN 80 PN 40

Engineered for high-temperature industrial environments, the Sensus WP-QF DN 80 PN 40 is a heavy-duty Woltman parallel turbine water meter designed to deliver precise measurement for extreme liquid temperatures up to 130°C and operating pressures up to 40 Bar.

Ideal for boiler systems, district heating networks, condensate recovery, and heavy industrial processing lines requiring long-term calibration stability and robust durability under severe service conditions.

Size DN 80 (3")
Rating PN 40 Bar
Max Temp 130°C
Type Woltman
Request Quote via WhatsApp View Technical Specifications
Industrial Grade 100% Genuine
Sensus Hot Water Meter WP-QF DN 80 PN 40 130°C

Sensus WP-QF DN 80

Hot Water Turbine Meter

Technical Specifications

Standard operating parameters and detailed configuration for Sensus WP-QF DN 80 PN 40.

DIN / EN Standards Compliant
Parameter Standard Configuration & Values
Brand & Product Series Sensus — WP-QF Series (Woltman Parallel Hot Water Meter)
Nominal Diameter (Size) DN 80 (3 Inches)
Meter Mechanism Type Axial Woltman Turbine / Parallel Flow Pattern
Pressure Rating (PN) PN 40 Bar (4.0 MPa / 580 PSI)
Maximum Water Temperature Up to 130°C (266°F)
Applicable Media High-Temperature Water, Boiler Feedwater, Steam Condensate, District Heating Systems
Body Material Construction Ductile Iron / Cast Steel with High-Grade Heat & Corrosion Resistant Coating
Flange Connections Flanged Standard EN 1092-2 / DIN PN 40
Register Counter Assembly Hermetically Sealed Dry Dial Counter (IP68 Water & Dust Protection)
Pulse Output Compatibility Optional Pulse Transmitter Ready (Compatible with HRI / OPTO Sensors)
