Mac Solenoid Valve 92 Series

The MAC 92 Series is a 4-way spool valve pilot operated by a small direct operated 4-way solenoid valve – a one-off in air valve manufacturing. The 4-way pilot means a low minimum operating pressure – no pistons – and minimal resistance to shifting. The balanced design in the pilot means shifting forces are consistently high and response times are repeatable regardless of inlet pressure fluctuations.

View Specifications

Product Specifications

Product Series	Mac Solenoid Valve 92 Series
Function Type	3-Way / 4-Way Spool Valve
Operating Media	Compressed Air,Inert Gases
Pressure Range	Vacuum to 120 PSI
Temperature Range	-18°C to 50°C (0°F to 120°F)
Flow Rate (Cv)	Up to 1.2 Cv (Depending on port configuration)
Coil Voltages	12V DC,24V DC,120V AC,240V AC (Optional)
Key Features	Balanced poppet design,ultra-fast response time,non-sticking operations even with poor air lubrication.
