Technical Specifications
Standard configuration and operational parameters for MAC Solenoid Operated 3-Way Valves.
| Parameter | Standard Configuration |
|---|---|
| Product Brand & Category | MAC Valves - Solenoid Operated 3-Way Series (e.g., 35, 100, 200 Series) |
| Valve Function | 3-Way, 2-Position (Normally Closed / Normally Open / Selector / Diverter) |
| Actuation Mechanism | Direct Solenoid Operated or Solenoid Pilot Operated |
| Applicable Medium | Compressed Air, Vacuum, Inert Gases (Lubricated or Non-Lubricated) |
| Operating Pressure Range | Vacuum to 120 PSI (0 to 8.2 bar) depending on model and coil power |
| Coil Voltage Options | 12VDC, 24VDC, 110VAC, 220VAC (50/60Hz) |
| Port Sizes / Connections | 1/8", 1/4", 3/8", 1/2" NPT / BSPP thread or Manifold Mount |
| Spool & Internal Design | Patented Balanced Poppet (Wipe-action, non-sticking design) |
| Ambient / Fluid Temperature Range | -18°C to 50°C (0°F to 120°F) |
| Enclosure Protection Rating | IP 65 / NEMA 4 (Grommet, Conduit, or DIN Connector) |
