Technical Specifications
Standard technical specifications and performance data for Victaulic Style W77/W77B AGS Flexible Coupling.
| Parameter | Standard Configuration |
|---|---|
| Product Brand & Model | Victaulic® Style W77 (Standard) / Style W77B (Wide Diameter/AGS Profile) Flexible Coupling |
| System Design | AGS (Advanced Groove System) - Patented wide-groove mechanical joint design |
| Function | Flexible Mechanical Pipe Joint / Accommodates Linear Movement, Angular Deflection, Thermal Expansion & Seismic Stress |
| Size Range (Nominal Diameter) | 14″ to 72″ / DN350 to DN1800 (AGS Roll Grooved or Cut Grooved Pipes) |
| Applicable Medium | Potable Water, Wastewater, Cooling Water, Slurry, Compressed Air, and Industrial Process Fluids |
| Maximum Working Pressure | Up to 350 psi / 2413 kPa (24 bar), depending on size, wall thickness, and pipe material |
| Housing Material | Ductile Iron conforming to ASTM A536, Grade 65-45-12 |
| Housing Coating / Finish | Orange Enamel, Hot-Dip Galvanized, or Custom Epoxy Coating |
| Gasket Options | Grade "E" EPDM (-30°F to +230°F / -34°C to +110°C) or Grade "T" Nitrile (-20°F to +180°F / -29°C to +82°C) with FlushSeal® design |
| Bolts & Nuts Material | Heavy-duty heat-treated Carbon Steel track bolts with zinc electroplate finish / Stainless Steel optional |
| Pipe Material Compatibility | Carbon Steel, Stainless Steel, and AGS-grooved metallic pipes |
| Standards & Approvals | UL Listed, FM Approved, VdS, LPCB, CE, AWWA C606 Compliant, and ISO 9001 Certified |
