Product Specifications
| Product Series | Brahma RE 3 Series Control Unit |
|---|---|
| Control Unit Type | Automatic Flame Safeguard & Gas/Oil Burner Controller |
| Supply Voltage | 230 VAC (+10% / -15%), 50–60 Hz (110 VAC option available) |
| Power Consumption | Approx. 3.5 VA |
| Flame Sensing System | Ionization Flame Rod / UV Sensor Phototube |
| Response Time | Safety Flame Failure Response < 1 sec |
| Operating Temperature | -20°C to +60°C (-4°F to +140°F) |
| Enclosure Protection Rating | IP40 (Standard Plug-in Socket Base) |
| Applications | Atmospheric gas burners, forced draught boilers, industrial heat treatment furnaces, and process heating systems. |
| Key Features | Fast flame detection reaction, highly stable signal processing, compact flame safeguard housing, quick plug-in socket installation, robust industrial protection, and integrated status monitoring. |
