General Specifications
Key mechanical properties and regulation performance standards for the Mecainox PZ4 V-BALL Valve system.
| Parameter | Standard Configuration |
|---|---|
| Valve Model & Type | Mecainox PZ4 V-BALL Regulating Control Ball Valve |
| Ball Configuration | V-Notch Ball Profile (30°, 60°, or Slotted V-Port Options for Precise Control) |
| Applicable Media | Steam, Thermal Liquids, Gases, Slurries, Corrosive Chemicals, Process Fluids |
| Body Materials | Stainless Steel (316L / 1.4404), Carbon Steel (A105 / WCB), High Alloys |
| Connection Sizes & Style | DN 15 to DN 100 (1/2" to 4") — Flanged, Threaded (BSP/NPT), Socket Weld, Butt Weld |
| Seat & Trim Options | TFM 1600, PEEK, Carbon-Filled PTFE, Metal-to-Metal Options |
| Pressure Rating | PN10 to PN40 / ASME Class 150 to Class 300 |
| Temperature Range | -50°C to +260°C (-58°F to +500°F) depending on seat selection |
| Actuation Integration | ISO 5211 Mounting Pad for Pneumatic / Electric Actuator & Positioner Setup |
Technical Datasheet & Manual
Review engineering drawings, flow coefficients (Kv/Cv curves), and modulating characteristics below.
