Product Specifications
| Product Series | OKM 612X / 615X Series |
|---|---|
| Valve Type | Rubber Seated Butterfly Valve (Wafer / Lug Type) |
| Nominal Size | 40 mm to 300 mm (1.5" to 12") — larger sizes available upon request |
| Pressure Rating | JIS 10K / PN10 / PN16 / ANSI 150# |
| Operating Temperature | -10°C to+120°C (depending on seat material selection) |
| Body Material | Ductile Iron (FCD450) / Cast Iron (FC250) / Stainless Steel |
| Seat & Disc Material | Seat:EPDM / NBR / FKM (Viton) | Disc:Stainless Steel 304 / 316 / Aluminum Bronze |
| Key Features | Bubble-tight bi-directional sealing,low operating torque,wear-resistant rubber seat lining,lightweight compact body structure,and versatile manual lever or gear actuator operation. |
