The OMB Class 600 Forged Steel Globe Valve features an A105 body construction with a 13% Cr trim and stellited seat for exceptional durability and wear resistance. Engineered with a bolted bonnet (BB), outside screw and yoke (OS&Y), reduced bore, graphite packing, 316 + graphite spiral wound gasket, and RF flange ends, it ensures reliable performance in high-pressure industrial applications.
View Specifications
| Brand | OMB |
|---|---|
| Pressure Class | Class 600 |
| Valve Type | Forged Steel Globe Valve |
| Body Material | A105 Forged Steel |
| Trim & Seat | 13% Cr Trim + Stellited Seat |
| Bonnet Design | Bolted Bonnet (BB) |
| Stem & Yoke | Outside Screw & Yoke (OS & Y) |
| Bore Type | Reduced Bore |
| Packing | Graphite Packing |
| Gasket | 316 + Graphite Spiral Wound Gasket |
| End Connection | RF Flange Ends |
