The OMB Class 800 Forged Steel Globe Valve features an A105 body construction with a 13% Cr trim and stellited seat for exceptional durability and wear resistance. Engineered with a bolted bonnet (BB),outside screw and yoke (OS&Y),reduced bore,graphite packing,316+graphite spiral wound gasket,and socket weld ends,it ensures reliable performance in high-pressure industrial applications.
View Specifications
| Brand | OMB |
|---|---|
| Pressure Class | Class 800 |
| Valve Type | Forged Steel Globe Valve |
| Body Material | A105 Forged Steel |
| Trim & Seat | 13% Cr Trim+Stellited Seat |
| Bonnet Design | Bolted Bonnet (BB) |
| Stem & Yoke | Outside Screw & Yoke (OS & Y) |
| Bore Type | Reduced Bore |
| Packing | Graphite Packing |
| Gasket | 316+Graphite Spiral Wound Gasket |
| End Connection | Socket Weld Ends |
